Inputs
1 MIC (6.35 mm jack)
1 MIC (XLR/Jack combo)
2 PHONO (RCA)
4 S/PDIF Digital (RCA)
6 CD/LINE (RCA)

Send/Return
1 RETURN (6.35 mm jack)
1 SEND (6.35 mm jack)

LAN 1
USB 1 USB B port

Outputs
1 BOOTH (6.35 mm jack)
1 HEADPHONE MONITOR (6.35 mm jack)
1 REC OUT (RCA)
1 S/PDIF Digital (RCA)
2 MASTER (XLR, RCA)


Display: 10 cm (3.94") bright dot matrix display
ProDJ Link: - Now On Play indicates that a CDJ deck is playing / - Beat Effects uses rekordbox BPM and Beatgrid information to synchronize effects / - Cue Link rekordbox acts as an additional audio channel to pre-listen to music through headphones.
Beat Effects : Delay, Echo, Spiral, Reverb, Trans, Filter, Flanger, Phaser, Robot, Melodic, Slip Roll, Roll, Reverse Roll
MIDI/HID control: 61 fully assignable MIDI controls
Number of channels: 4
Sample rate / depth: 96 kHz / 24-bit
rekordbox™ Link: Yes

Channels

Equalizer per channel: 3-band
3-Band Equalizer: Built-in switchable 3-band equalizer (+6dB to -26dB) and 3-way isolator (+6dB to -∞dB).
Fader curves : 3 curves
Level meter : Individual
Meter size : 15 segments

Input

CD/LINE input (RCA) : 6
PHONO Input (RCA): 2
S/PDIF Digital Input (RCA): 4
Digital LAN Input (Pioneer Link): 1
MICRO Input (6.35 jack): 1
MIC Input (XLR/Jack Combo): 1
Effects Return (6.35 jack): 1

Output

Master Output (XLR): 1
Master Output (RCA): 1
Return Output (Jack 6.35) : 1
Recording Output (RCA) : 1
Digital Output (Coaxial): 1
S/PDIF Digital Output (RCA): 1
Effects Out (6.35 jack): 1
USB-B: 1


Master

Master Balance : Yes
Stereo/Mono Switch : Yes
Meter size : 15 segments
Output level attenuator : Yes

Cross Fader

Cross Fader (+) : Carbon rail with P-Lock fader
Fader Curve: 3
Assignable : Yes
Field replaceable : Yes

Effects/Sampler

Automatic BPM meter : Yes
Effect depth adjustment : Yes
MIDI global clock : Yes
rekordbox Quantize : Yes
Roll Sampler (front) : Yes
Roll Sampler (rear) : Yes
Twin LFO : Yes
Sound Processor : 32 bits
X-PAD : Yes

Microphone

Mic connection: Neutrik combo
Mic equalizer : 2 bands
Mic equalizer per band: + - 12 dB
Talkover : 3 position switch
Automatic talkover : Yes


Midi Info

Assignable Controls : 61
MIDI Output (DIN) : 1
MIDI Start/Stop : Yes
MIDI LFO : Yes


Sound card

Connection : USB
Stereo inputs: 4
Stereo Outputs: 4
Sample rate: 24-bit
Frequency : 96 kHz
Special Features: - Direct signal from all four TRAKTOR channels via 1 USB cable: - Certified TRAKTOR SCRATCH / - Ability to output a timecoded disc signal for DVS software


Specifications

Auto Standby : Yes
SN Ratio: Line : 107 dB
Sampling frequency : 96 kHz
A/D Converter : 32-bit
D/A Converter: 32-bit
Frequency Response: 20 Hz to 20 kHz
Harmonic distortion: < 0.004%.
Headroom: 19 dB
Rack mountable : Yes, with adapter
Width 331 mm
Height 108 mm
Depth 409 mm
Weight: 7.1 kg
