Inputs
1 x DisplayPort up to 4K @ 30 Hz
1 x HDMI up to 4K @ 30 Hz
1 x 6G-SDI
1 x 6G-SDI Loop-through
1 x Universal Analog
1 x DVI Dual-Link up to 2560 x 1600 @
60 Hz
1 x Video Optical SFP Module cage
1 x HDMI up to 2K/1080p (front panel)
1 x 3.5 mm jack for stereo audio (front
panel)
1 x Genlock
1 x Genlock Loop-through
Outputs
1 x DisplayPort up to 4K @ 30 Hz
1 x HMDI up to 4K @ 30 Hz
1 x 6G-SDI Compliant Level A
1 x 6G-SDI Compliant Level B
1 x Universal Analog
1 x DVI Dual-Link up to 2560 x 1600 @
60 Hz
1 x Video Optical SFP Module cage
1 x 1/4” / 6.35 mm stereo jack for head
phones (front panel
Power Supply 100 to 240 VAC 50/60 Hz, 3.2 A
Power Consumption 120 W
Dimensions 17.3 x 15.75 x 3.46” (43.9 x 40.0 x 8.8
cm)
Weight 13.7 lb (6.2 kg)
