Screen
Screen size
65"

Panel
New Edge, 60Hz
Resolution
3,840 x 2,160

Pixel size (HxV)
0.372(H) x 0.372(V)
Brightness (normal)
350

Contrast
6,000:1
Angle of view (H/V)
178/178

Response Time
8ms(Tip)
Color range
72%

Glass Haze
0.02%
H-Scanning frequency
30~81kHz

Maximum pixel frequency
594Mhz
V-Scanning frequency
48~75Hz

Contrast ratio (Dynamic)
Mega
Connectivity
HDMI In
2

DP In
No
DVI In
1(DVI-D)

USB
2
IR In
Yes

HDBaseT In
No
Audio input
Yes

Audio Output
Stereo mini jack
Video output
No

RS232 In
Yes
RS232 Out
Yes

RJ45 In
Yes
RJ45 Out
No

WiFi
Yes
3G Dongle
No

Bluetooth
No
Energy consumption
Power supply
AC100-240V 50/60Hz

Consumption (Ignition)
176
Consumption (Rest)
0.5 W
Measures
Set dimensions (width x height x depth)
1457.5 x 837.3 x 59.4 mm

Dimensions packed (AnxAltxProf)
1601 x 970 x 178 mm
Weight
Set weight
25.3 kg

Package weight
31.10 kg
Operation
Temperature
0 ~ 40

Humidity
10~80%
Mechanical characteristics
VESA assembly
400 x 400 mm

Frame width
10.5(top, side), 11.8(bottom)
Frame Material
No shine
