Video

Number of cameras
1
Camera resolution
13 megapixels
Image sensor
1/3.2"
Zoom
Up to 3x lossless digital zoom at 720p
Field of view
Horizontal: 90°, Vertical: 75°, Diagonal: 117°
Resolution
4k Ultra-HD: 3840 x 2160 @ 30 fps

1080p Full HD: 1920 x 1080 @ 30 fps

720p HD: 1280 x 720 @ 30 fps
Focal length
2.26mm
Aperture
2.25
Intelligent Zoom
Yes
Vivid HDR
Yes
Picture in Picture (PIP)
Yes

Audio

Microphone type
MEMS
Number of microphones
3
Microphone sensitivity
-37dBFS
Microphone frequency range
100Hz - 8000Hz

Software & Apps

System requirements
Compatible with Windows 11, Windows 10, Windows 8.1 (64-bit and 32-bit), macOS 10.15 and later, including macOS 11.x
Compatible software and/or apps
Jabra Direct, Jabra Xpress
Software Development Kit (SDK)
Yes

Ease of Use

Manual Pan-Tilt-Zoom (PTZ)
Yes

Connectivity

Connectivity
USB-C
Supported USB versions
USB 3.0, USB 2.0 (supplying more than 500mA of current)
UVC versions
1.1

General

Box contents
PanaCast 20, carry case, USB-C to USB-A cable 1.5m/4.9ft (USB 3.0)
Packaging dimensions (WxHxD)
160mm x 50mm x 130mm | 6.3in x 2in x 5.2in
Main unit dimensions (WxHxD)
44mm x 25mm x 80mm | 1.73in x 1in x 3.14in
Weight
136g | 4.9oz
Warranty
2 years
Certifications and compliance
Microsoft Teams, Zoom, Works with all leading UC platforms
Operating temperature
5°C to 35°C | 41°F to 95°F
Storage temperature
-20°C to 60°C | -4°F to 140°F
