4K video output with horizontal resolution of 2000 television lines thanks to a large 11-megapixel sensor.
Supports 1/100 second high-speed reading to control continuous shutter distortion.
Compatible with high dynamic range (HDR) and a wide range of colors according to BT.2020 from ITU-R (with the AK-UCU600 connected)
Compatible with HD high-speed mode (2x) (with the AK-UCU600 connected)
Output 12G-SDI / TICO over output SDI / (with the AK-UCU600 connected). Compatible with SMPTE ST2110 with optional equipment (with the AK-NP600).
The AK-UC3300 supports UHD and HD acquisition and also supports multiple formats simultaneously.
Supported formats:
UHD
2160/59.94p, 2160/50p, 2160/29.97p,
2160/25p, 2160/23.98p, 2160/29,97PsF,
2160/25PsF, 2160/23.98PsF,
2160/23.98PsF and about 59.94i
HD
1080/59.94p, 1080/50p, 1080/59.94i,
1080/50i, 1080/29,97PsF, 1080/25PsF,
1080/23.98PsF
720/59.94p, 720/50p
High speed HD
1080/59.94p-120fps, 1080/50p-100fps,
